LifeWindow 9x

Category: Tag:

Description

Multiparameter Veterinary Monitor

Digicare’s LifeWindow LW9x is a multi-parameter veterinary monitor built with premium measurement modules, to deliver unprecedented reliability. The large 12.1’’ touch screen makes the LifeWindow LW9x very easy to navigate. Using only veterinary specific modules this device measures all patient sizes and species through small and large modes. All vital signs are saved in an MS Excel and PDF spreadsheets that can be easily transferred to any practice management software via networking or a USB drive. All reports and EKGs can be printed either to a standard printer, to a PDF document, or to an optional strip chart printer. The LifeWindow LW9x remote access and control features allow you to view your patient from anywhere at any time so you will never miss a beat.



Accuracy Matters

LifeWindow is built to improve patient outcomes by delivering quick and accurate measurements from critical care to routine checkups on any species. This device is equipped with clinically validated measurement modules that are backed by years of research.

Measurements

  • Electrocardiography

    Digicare’s VetECG™ utilizes an advanced algorithm based on spectrum analysis developed using ECG data acquired from numerous animal recordings. Backed by extensive testing in general practice, universities, and zoos our ECG technology is proven to deliver reliable readings for research and clinical purposes.

  • Pulse Oximetry

    Proven in 150 independent clinical studies, Masimo’s® pulse oximetry has been the leading technology for veterinarians around the world. Accurate SpO2 readings are provided during challenging conditions such as low perfusion, caused by Alpha II agonists and Propophol, and motion.

  • Capnography

    Our capnography solutions provide comprehensive measurements including End-tidal, inspired, and a real time CO2 waveform. Options for mainstream and/or sidestream are available for monitoring your patient’s every breath.

  • Non-Invasive BP

    Obtaining reliable BP measurements from animals can be challenging. Suntech’s® VetBP™ module uses an animal specific algorithm designed with motion tolerant technology. Whether it be a routine check-up or a procedure, the readings will be timely and precise for any species.

  • Temperature

    Digicare’s temperature module is thoroughly calibrated for veterinary patient use. Our temperature probes are constructed of high quality rubber. The rubber’s flexibility allows for easy rectal or esophageal placement. Temperature is included in all models the probe sold separately.

  • Invasive BP

    Patients arterial pressure is measured using specially calibrated pressure sensors passing through a high quality arterial line. These invasive channels can be specifically labeled to reflect up to 2 channels for placement in various locations.

  • FIO2

    Fraction of inspired oxygen is a plug and play measurement that can be added at any time by purchasing the required accessories.

  • Cardiac Output

    Providing essential hemodynamic measurements like cardiac output, stroke volume, right ejection fraction, and a collection of other hemodynamic direct and indirect measurements. All measurements are taken intermittently using the PA catheter and thermodilution technology.
